MOSFET_P type
| Product | Package | Configuration | Type | ESD Diode | Pd(W) | Max Rating | Vgs(th) | Rdson（mohm） | gui规格规格书 | |||||||||
| Vds | Id | Vgs | Min | Typ | Max | at Vgs=10V | at Vgs=4.5V | at Vgs=2.5V | Datasheet 规格下载 | |||||||||
| (V) | (A） | (+/-V) | (V) | (V) | (V) | Tpy | Max | Typ | Max | Typ | Max | |||||||
| DUP2301 | SOT-23 | Single | P | No | 1.25 | -20 | -3 | 12 | -0.5 | -1 | 65 | 90 | 90 | 115 | ||||
| DUP3415E | SOT-23 | Single | P | Yes | 1.4 | -20 | -4 | 8 | -0.3 | -0.55 | -1 | 37 | 43 | 45 | 54 | |||
| DUP4407 | SOP-8 | Single | P | No | 1.9 | -20 | -5.4 | 12 | -0.3 | -0.55 | -1 | 37 | 43 | 45 | 52 | |||
| DUP4953 | SOP-8 | Dual | P | No | 2 | -30 | -5.3 | 20 | -1 | -3 | 46 | 53 | 70 | 85 | ||||
| DUP9435 | SOP-8 | Single | P | No | 2.5 | -30 | -5.3 | 20 | -1 | -3 | 46 | 53 | 70 | 85 | ||||
| DUP3641 | SOP-8 | Dual | P | No | 2 | -30 | -5 | 12 | -0.7 | -1.3 | 41 | 49 | 53 | 64 | ||||
| DUP3401 | SOT-23 | Single | P | No | 1 | -30 | -4.2 | 12 | -0.7 | -2 | 42 | 50 | 53 | 65 | 80 | 120 | ||
| DU30P25D | TO-252 | Single | P | No | 41 | -30 | -25 | 20 | -1.2 | -2.4 | 19 | 35 | 29 | 58 | ||||
| DU30P85D | TO-252 | Single | P | No | 100 | -30 | -85 | 25 | -1.5 | -2.5 | -3.5 | 5.1 | 6 | 6.3 | 7.5 | |||
| DUP40P20D | TO-252 | Single | P | No | 75 | -40 | -20 | 20 | -1 | -3 | 12 | 15 | 20 | 25 | ||||
| LBSS84 | SOT23 | Single | P | Yes | 230m | -50 | -130m | 20 | -0.8 | -2 | 2.1R | 7R | ||||||
| DU60P26A | TO-263 | Single | P | No | 60 | -60 | -26 | 20 | -1 | -1.8 | -2.5 | 31 | 40 | 42 | 55 | |||
| DU60P26D | TO-252 | Single | P | No | 60 | -60 | -26 | 20 | -1.2 | -1.8 | -2.4 | 32 | 40 | 43 | 55 | |||
