SJMOS
| Product | Package | Configuration | Type | ESD Diode | Pd(W) | Max Rating | Vgs(th) | Rdson（mohm） | Datasheet下载 | |||||||||
| Vds | Id | Vgs | Min | Typ | Max | at Vgs=10V | at Vgs=4.5V | at Vgs=2.5V | ||||||||||
| (V) | (A） | (+/-V) | (V) | (V) | (V) | Tpy | Max | Typ | Max | Typ | Max | |||||||
| DU11NS60 | TO220 | Single | N | No | 162 | 600 | 11 | 30 | 2 | 4 | 0.36R | 0.41R | ||||||
| DU11NS60F | TO220F | Single | N | No | 32.8 | 600 | 11 | 30 | 2 | 4 | 0.36R | 0.41R | ||||||
| DU11NS60D | TO252 | Single | N | No | 125 | 600 | 11 | 30 | 2 | 4 | 0.36R | 0.41R | ||||||
| DU18NS60 | TO220 | Single | N | No | 156 | 610 | 15 | 30 | 2 | 4 | 0.27R | 0.35R | ||||||
| DU18NS60F | TO220F | Single | N | No | 32.8 | 610 | 15 | 30 | 2 | 4 | 0.27R | 0.35R | ||||||
| DU20NS60 | TO220 | Single | N | No | 208 | 600 | 20 | 30 | 2 | 4 | 0.17R | 0.19R | ||||||
| DU20NS60F | TO220F | Single | N | No | 34.7 | 600 | 20 | 30 | 2 | 4 | 0.17R | 0.19R | ||||||
| DU26NS60 | TO220 | Single | N | No | 208 | 600 | 20 | 30 | 2 | 4 | 0.135R | 0.165R | ||||||
| DU20N60H | TO247 | Single | N | No | 208 | 600 | 20 | 30 | 2 | 4 | 0.2R | 0.3R | ||||||
| DU7NS65G | TO251 | Single | N | No | 83 | 650 | 7 | 30 | 2 | 4 | 0.58R | 0.65R | ||||||
| DU11NS65 | TO220 | Single | N | No | 162 | 680 | 11 | 30 | 2 | 4 | 0.36R | 0.41R | ||||||
| DU11NS65F | TO220F | Single | N | No | 32.8 | 680 | 11 | 30 | 2 | 4 | 0.36R | 0.41R | ||||||
| DU20NS65 | TO220 | Single | N | No | 208 | 680 | 20 | 30 | 2 | 4 | 0.18R | 0.2R | ||||||
| DU20NS65F | TO220F | Single | N | No | 34.7 | 680 | 20 | 30 | 2 | 4 | 0.18R | 0.2R | ||||||
| DU5NS70G | TO251 | Single | N | No | 50 | 700 | 5 | 30 | 2 | 4 | 1.23R | 1.4R | ||||||
| DU6NS70G | TO251 | Single | N | No | 50 | 700 | 5.2 | 30 | 2 | 4 | 1.2R | 1.4R | ||||||
